Xerox VersaLink C625 Models:-
- Xerox VersaLink C625DN
- Xerox VersaLink C625DNW
- Xerox VersaLink C625 Printer repair maintenance, servicing, routine maintenance
- Xerox VersaLink C625 Fault code diagnosis, repair
- Xerox VersaLink C625 Printer repairs installed, relocated
- Xerox VersaLink C625 network installation, setup, issues resolved
- Xerox VersaLink C625 scan to email setup programmed
- Xerox VersaLink C625 poor print quality resolved, repaired, fixed
- Xerox VersaLink C625 Printer repair paper jams repaired
- Xerox VersaLink C625 end of life component replacement ie Drums, ITB Belts, Fuser Units, Transfer Rollers
Xerox VersaLink C625 local mobile on site repairs and servicing
Mobile on-site Xerox VersaLink C625 printer repairs and servicing across West Sussex, East Sussex, Surrey and Kent.
Xerox VersaLink C625 Details:
The Xerox Versalink C625 is Xerox’s new all-in-one colour solution for the high-demands of the busy modern workplace. Small enough to fit anywhere, the C625 offers a complete package to assist high-performing work teams.
Compact package with no compromises
Built to cope with high output print volumes and demanding scanning tasks, the Xerox C625 offers print speeds of up to an impressive 50 A4 pages per minute (ppm) in both colour and mono. For those producing double-sided documents, the C625 delivers duplexing at an incredible 38 A4 ppm.
For scanning, the most demanding jobs are handled in a breeze with the single-pass DADF (Duplex Automatic Document Feeder) processing a huge 98 sides per minute, working in harmony with a host of connected productivity apps such as DropBox , Microsoft OneDrive, Google Drive and many more.
Xerox VersaLink C625 Specifications: VIEW XEROX C625 DATA SHEET
- Introduction Date: Introduction Date 09/2023
- Paper Capacity: Paper Capacity 550 Sheets
- Toner Cartridge Standard, Black: 006R04616 - Yield, Black Estimated 8,000 @ 5%
- Toner Cartridge Metered, Black: 006R04648 - Yield, Black Estimated 20,000 @ 5%
- Toner Cartridge Hi-Capacity, Black: 006R04616 - Yield, Black Estimated 25,000 @ 5%
- Toner Cartridge Standard Yield, Cyan: 006R04636 - Yield, Cyan Estimated 6,000 @ 5%
- Toner Cartridge Metered, Cyan: 006R04649 - Yield, Cyan Estimated 12,000 @ 5%
- Toner Cartridge Hi-Capacity, Cyan: 006R04637 - Yield, Cyan Estimated 16,000 @ 5%
- Toner Cartridge Standard Yield, Magenta: 006R04618 - Yield, Magenta Estimated 6,000 @ 5%
- Toner Cartridge Metered, Magenta: 006R04650 - Yield, Magenta Estimated 12,000 @ 5%
- Toner Cartridge Hi-Capacity, Magenta: 006R04638 - Yield, Magenta Estimated 16,000 @ 5%
- Toner Cartridge Standard Yield, Yellow: 006R04616 - Yield, Yellow Estimated 6,000 @ 5%
- Toner Cartridge Metered, Yellow: 006R04651 - Yield, Yellow Estimated 12,000 @ 5%
- Toner Cartridge Hi-Capacity, Yellow: 006R04639 - Yield, Yellow Estimated 16,000 @ 5%
- Pages per Minute, Black: Pages per Minute, Black 25 ppm
- Monthly Duty Cycle: Monthly Duty Cycle 150,000.00 Impressions
- First Page Print Time: First Page Print Time 5.8 sec
- Two-Sided Printing: Two-Sided Printing Auto
- Supported Page Size: Supported Page Size up to 11.7" x 17"
- Memory, Maximum: Memory, Maximum 4-GB RAM, 320-GB HD
Xerox VersaLink C625 Paper Jams
Paper jams are usually associated with either paper feed issues or the fuser unit
- Paper feed issues, we carry in stock new Xerox VersaLink C625 paper feed tires to replace worn tires. When tires are worn they can leave a grey smudge on the top sheet of paper in the paper tray, this is caused by the worn roller slipping on the paper. Paper feed issues are synonymous with the jam indicator coming on but no paper being found in the printer.
- Fuser jams - the fuser unit is similar to an old fashioned mangle, with its rollers being heated to 200’ centigrade. The heat roller is covered with a Teflon film to prevent toner sticking to it. When the fuser film wears the Teflon allows the Toner to stick to it, this will cause paper jams. Fuser unit jams can result in concertinaed paper being found in the machine.
If your Xerox VersaLink C625 is jamming we carry in stock new paper feed tires and fuser units, we can attend site and rectify your jamming issues for you.
Call 01293 326406 or email sales@dos-crawley.co.uk to place a service call
Xerox VersaLink C625 Print Quality Issues
Print quality issues can caused by several factors
- Poor quality consumables, toner cartridges can develop faults leading to print quality issues. Compatible cartridges give even more issues, make sure you purchase good quality consumables from a reputable source, we warrant our compatible cartridges for use in Xerox VersaLink C625 printers.
- The Xerox VersaLink C625 uses separate drum units, these wear and will give issues with print quality.
- Contamination of the laser mirrors will lead to poor print quality, we can strip and clean your Xerox VersaLink C625 printer optics.
- The Xerox VersaLink C625 is prone to contamination of the Waste toner system on the Transfer Belt, as the name implies the Xerox VersaLink C625 Transfer Belt combines black, cyan, magenta and yellow images on the belt to produce a full Color image. This is then transferred to the paper by the Secondary Transfer Roller, issues with the Transfer System will usually give smeared or banding issues. We can repair your Xerox VersaLink C625 if it develops a Transfer Belt issue.
Xerox VersaLink C625 Common fault codes
Fault Code 062-380:- Abnormality detected in Laser Unit, replacing the Laser Unit is a very big job, for customers experiencing this fault in the past, we have swapped the clients consumables into a refurbished Xerox VersaLink C625 body, which proves quicker and cheaper than a lengthy repair to their own machine.
Fault Code 062-380:- Insufficient Lamp Brightness was Detected When Performing AGC - We have refurbished scanner, document feeder assemblies we can fit a refurbished unit to resolve this error.
We offer on-site local Xerox VersaLink C625 printer print quality repairs in West Sussex, East Sussex, Surrey and Kent.
Xerox VersaLink C625 Printer Offline - Network connection issues
Xerox VersaLink C625 printer offline, unable to connect, our engineers can diagnose and resolve physical connection issues and driver related issues.Our engineers carry wireless print servers, network switches and a wide assortment of USB and Ethernet cables.
We can resolve multi-function printers to scan, scan to email or folder related issues.
Xerox VersaLink C625 Installation
We offer on-site local Xerox VersaLink C625 printer installation in West Sussex, East Sussex, Surrey and Kent. Even if you purchased your Xerox VersaLink C625 elsewhere, we can assist in its installation. Our Xerox trained engineers can install your Xerox VersaLink C625 for use with Apple and Microsoft operating systems.
Our engineers carry wireless print servers, network switches and a wide assortment of USB and Ethernet cables.
We can set up multi-function printers to scan, scan to email or folder.
We have mobile service engineers who can carryout on-site Xerox VersaLink C625 printer repairs and servicing across West Sussex, East Sussex, Kent and Surrey call 01293 326406 or email sales@dos-crawley.co.uk to place a service call
